i.MX 6Quad Processor 1GHz
2GB DDR3 SDRAM
Connectivity
- Mini PCIe connector
- SATA 22-pin connector
- Micro SD/MMC card slots
- 10/100/1000 Ethernet Port
- 1 xMini USB 2.0 OTG connector
- eMMC 4.3 connector
Display
- MIPI DSI 지원
- 2 x LVDS connectors
- HDMI display interface connector
Audio : WM8960 Stereo audio codec
USB Host 2.0 : 2 Port (Full Speed)
Camera : Parallel x 1 , MIPI x 1
UART : UART1 (Debug)
Power : DC-JACK 5V, 1A
Button : Button : 2
Boot Switch : 1
LED indicator : 2
Expansion Connector ( 60x1 ) : EBI,UART,I2C GPIO etc
Dimensions : base 120 x 76 mm CPU 50 x 40mm
